Characteristic | ||
Horizontal cold air, overhead valve (OHV) design, strong power, reliability and durability, the pump body is made of ADC12 aluminum alloy casting, professional balance and low gravity design, so that the smooth operation of the engine low fuel consumption, low noise, energy saving and environmental protection, Environmental protection. | ||
The six core escort for you | ||
Strong power | ||
All Steel Crankshaft | ||
Forged piston | ||
Low fuel consumption | ||
Factory inspection | ||
Quality assurance | ||
Detailed parameters | ||
Model | Manual diesel engine | Diesel mechanical start |
Engine category | Four stroke,overhead valve,horizontal shaft air-cooled, Single cylinder gasoline engine | |
Maximum output | 4.0HP(2.9kw)3000r/min | 4.0HP(2.9kw)3000r/min |
Displacement | 196CC | 196CC |
Cylinderbore x trip | 68 x 54 | 68 x 54 |
Startup mode | Recoil manual start | Recoil manual start of electric start |
Lubricating oil capacity | 0.7L | 0.7L |
Gross weight | 22kg | 24kg |
Overall dimension | 39x34x38cm | 39x34x38cm |
